SLIMs Narrow Plastic Feedthrough Connectors - Front Mounting
The FT series of true, feed through, data connectors for electrical instrumentation are perfect for developing custom I/O configurations for wall plates, rack panels, etc.
The SLIMs are 19 × 35.5 mm, fit within a narrow 17.15 × 22.86 mm panel cutout and use common cabling for front and back connections. No soldering and no punch terminations - just use the standard cable for that particular connector style.
Mount from the front with various mounting hole options. Low rear profile.
Available in a variety of styles. Functionality is affected by cable quality, length and cable wiring configuration.
Please also see our feedthrough connectors, XLR audio and XLR format connectors and USB connectors.
-
HDMI female to HDMI female SLIM narrow plastic front mounting feedthrough connector.
- CP30600G 3.2mm countersunk mounting holes (90° × ⌀5.85mm).
- CP30600GX 2.5mm diameter plain mounting holes.
- CP30600GX1 3.2mm diameter plain mounting holes.
-
Mini Displayport female to female SLIM narrow plastic front mounting feedthrough connector.
- CP30602 3.2mm countersunk mounting holes (90° × ⌀5.85mm).
- CP30602X 2.5mm diameter plain mounting holes.
- CP30602X1 3.2mm diameter plain mounting holes.
-
USB 3.0 A female to USB 3.0 A female SLIM narrow plastic front mounting feedthrough connector.
- CP30605N 3.2mm countersunk mounting holes (90° × ⌀5.85mm).
- CP30605NX 2.5mm diameter plain mounting holes.
- CP30605NX1 3.2mm diameter plain mounting holes.
-
USB 3.0 B female to USB 3.0 A female SLIM narrow plastic front mounting feedthrough connector.
- CP30606N 3.2mm countersunk mounting holes (90° × ⌀5.85mm).
- CP30606NX 2.5mm diameter plain mounting holes.
- CP30606NX1 3.2mm diameter plain mounting holes.
-
USB 2.0 B female to USB 2.0 A female SLIM narrow plastic front mounting feedthrough connector.
- CP30607N 3.2mm countersunk mounting holes (90° × ⌀5.85mm).
- CP30607NX 2.5mm diameter plain mounting holes.
- CP30607NX1 3.2mm diameter plain mounting holes.
-
USB 2.0 A female to USB 2.0 A female SLIM narrow plastic front mounting feedthrough connector.
- CP30608N 3.2mm countersunk mounting holes (90° × ⌀5.85mm).
- CP30608NX 2.5mm diameter plain mounting holes.
- CP30608NX1 3.2mm diameter plain mounting holes.
-
USB 2.0 A female to USB 2.0 B female SLIM narrow plastic front mounting feedthrough connector.
- CP30609N 3.2mm countersunk mounting holes (90° × ⌀5.85mm).
- CP30609NX 2.5mm diameter plain mounting holes.
- CP30609NX1 3.2mm diameter plain mounting holes.
-
USB Type-C female to USB Type-C male SLIM narrow plastic front mounting feedthrough connector.
USB-C extension cables available.
- CP30611 3.2mm countersunk mounting holes (90° × ⌀5.85mm).
- CP30611X 2.5mm diameter plain mounting holes.
- CP30611X1 3.2mm diameter plain mounting holes.
-
UTP Unshielded Cat.5e RJ45 SLIM narrow plastic front mounting feedthrough connector.
- CP30620 3.2mm countersunk mounting holes (90° × ⌀5.85mm).
- CP30620X 2.5mm diameter plain mounting holes.
- CP30620X1 3.2mm diameter plain mounting holes.
-
FTP Shielded Cat.5e RJ45 SLIM narrow plastic front mounting feedthrough connector.
- CP30620S 3.2mm countersunk mounting holes (90° × ⌀5.85mm).
- CP30620SX 2.5mm diameter plain mounting holes.
- CP30620SX1 3.2mm diameter plain mounting holes.
-
UTP Unshielded Cat.6 RJ45 SLIM narrow plastic front mounting feedthrough connector.
- CP30622 3.2mm countersunk mounting holes (90° × ⌀5.85mm).
- CP30622X 2.5mm diameter plain mounting holes.
- CP30622X1 3.2mm diameter plain mounting holes.
-
FTP Shielded Cat.6 RJ45 SLIM narrow plastic front mounting feedthrough connector.
- CP30622S 3.2mm countersunk mounting holes (90° × ⌀5.85mm).
- CP30622SX 2.5mm diameter plain mounting holes.
- CP30622SX1 3.2mm diameter plain mounting holes.
-
Cat.3 RJ11 / RJ14 (6P4C) SLIM narrow plastic front mounting feedthrough connector.
- CP30623 3.2mm countersunk mounting holes (90° × ⌀5.85mm).
- CP30623X 2.5mm diameter plain mounting holes.
- CP30623X1 3.2mm diameter plain mounting holes.
-
FTP Shielded Cat.6a RJ45 SLIM narrow plastic front mounting feedthrough connector.
- CP30625S 3.2mm countersunk mounting holes (90° × ⌀5.85mm).
- CP30625SX 2.5mm diameter plain mounting holes.
- CP30625SX1 3.2mm diameter plain mounting holes.
-
BNC 50 Ohm SLIM narrow plastic front mounting feedthrough connector.
- CP30637 3.2mm countersunk mounting holes (90° × ⌀5.85mm).
- CP30637X 2.5mm diameter plain mounting holes.
- CP30637X1 3.2mm diameter plain mounting holes.
-
BNC 75 Ohm SLIM narrow plastic front mounting feedthrough connector.
- CP30638 3.2mm countersunk mounting holes (90° × ⌀5.85mm).
- CP30638X 2.5mm diameter plain mounting holes.
- CP30638X1 3.2mm diameter plain mounting holes.
-
Blanking plate SLIM narrow plastic front mounting feedthrough connector.
- CP30641 3.2mm countersunk mounting holes (90° × ⌀5.85mm).
- CP30641X 2.5mm diameter plain mounting holes.
- CP30641X1 3.2mm diameter plain mounting holes.
-
SLIM / DUALSLIM Gaskets and Dust Covers.
These rubber gaskets are used as dust seals and for colour color identification.
- CP299812 Black SLIM / DUALSLIM gasket.
- CP299815 Green SLIM / DUALSLIM gasket.
- CP299817 Red SLIM / DUALSLIM gasket.
- CP299818 Blue SLIM / DUALSLIM gasket.
- CP299822 Black DUALSLIM (countersunk) gasket with dust cover.
- CP299825 Green DUALSLIM (countersunk) gasket with dust cover.
- CP299827 Red DUALSLIM (countersunk) gasket with dust cover.
- CP299828 Blue DUALSLIM (countersunk) gasket with dust cover.
- CP299832 Black DUALSLIM (countersunk) dust cover.
- CP299835 Green DUALSLIM (countersunk) dust cover.
- CP299837 Red DUALSLIM (countersunk) dust cover.
- CP299838 Blue DUALSLIM (countersunk) dust cover.
Please contact Cliff™ sales for more information.
