SLIMs Narrow Metal Feedthrough Connectors - Front Mounting
The FT series of true, feed through, data connectors for electrical instrumentation are perfect for developing custom I/O configurations for wall plates, rack panels, etc.
The SLIMs are 19 × 35.5 mm, fit within a narrow 17.15 × 22.86 mm panel cutout and use common cabling for front and back connections. No soldering and no punch terminations - just use the standard cable for that particular connector style.
Mount from the front with various mounting hole options. Low rear profile.
Available in a variety of styles. Functionality is affected by cable quality, length and cable wiring configuration.
Jump down to BNC, DisplayPort, HDMI, RJ11, RJ45, USB 2, USB 3, USB-C, Blanks, Dust Covers.
Please also see our feedthrough connectors, XLR audio and XLR format connectors and USB connectors.
BNC
-
BNC 50 Ohm SLIM narrow, metal, front-mounting, feedthrough connector.
- CP30637M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30637MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30637MX1 Nickel frame with 3.2 mm diameter plain mounting holes.
- CP30637MBX1 Black metal frame with 3.2 mm diameter plain mounting holes.
-
BNC 75 Ohm SLIM narrow, metal, front-mounting, feedthrough connector.
- CP30638M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30638MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30638MX1 Nickel frame with 3.2 mm diameter plain mounting holes.
- CP30638MBX1 Black metal frame with 3.2 mm diameter plain mounting holes.
DisplayPort
-
DisplayPort female to female SLIM narrow, metal, front-mounting, feedthrough connector. 8K @ 60Hz. Gold-plated contacts.
DisplayPort to DisplayPort cables are available in 1m and 2m lengths.
- CP30633M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30633MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30633MX1 Nickel frame with 3.2 mm diameter plain mounting holes.
- CP30633MBX1 Black metal frame with 3.2 mm diameter plain mounting holes.
-
Mini DisplayPort female to female SLIM narrow, metal, front-mounting, feedthrough connector. Gold-plated contacts.
DisplayPort to mini DisplayPort cables are available in 1m and 2m lengths.
- CP30602M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30602MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30602MX1 Nickel frame with 3.2 mm diameter plain mounting holes.
- CP30602MBX1 Black metal frame with 3.2 mm diameter plain mounting holes.
HDMI
-
HDMI 4K female to HDMI 4K female SLIM type-A, narrow, metal, front-mounting, feedthrough connector. Gold-plated contacts and shell.
- CP30600GM Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30600GMB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30600GMX1 Nickel frame with 3.2 mm diameter plain mounting holes.
- CP30600GMBX1 Black metal frame with 3.2 mm diameter plain mounting holes.
-
HDMI 8K female to HDMI 8K female SLIM type-A, narrow, metal, front-mounting, feedthrough connector. Gold-plated contacts and shell.
Shielded HDMI 2.1 supporting 7680 × 4320 at 60 Hz with HDR video support.
- CP30688M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30688MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30688MX1 Nickel frame with 3.2 mm diameter plain mounting holes.
- CP30688MBX1 Black metal frame with 3.2 mm diameter plain mounting holes.
RJ11 / RJ14
-
RJ11 / RJ14 (6P4C) Cat.3 SLIM narrow, metal, front-mounting, feedthrough connector. Gold-plated contacts.
- CP30623M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30623MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30623MX1 Nickel frame with 3.2 mm diameter plain mounting holes.
- CP30623MBX1 Black metal frame with 3.2 mm diameter plain mounting holes.
RJ45
-
RJ45 Cat.5e Unshielded UTP SLIM narrow, metal, front-mounting, feedthrough connector. Gold-plated contacts.
- CP30620M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30620MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30620MX1 Nickel frame with 3.2 mm diameter plain mounting holes.
- CP30620MBX1 Black metal frame with 3.2 mm diameter plain mounting holes.
-
RJ45 Cat.5e Shielded FTP SLIM narrow, metal, front-mounting, feedthrough connector. Gold-plated contacts.
- CP30620SM Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30620SMB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30620SMX1 Nickel frame with 3.2 mm diameter plain mounting holes.
- CP30620SMBX1 Black metal frame with 3.2 mm diameter plain mounting holes.
-
RJ45 Cat.6 Unshielded UTP SLIM narrow, metal, front-mounting, feedthrough connector. Gold-plated contacts.
- CP30622M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30622MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30622MX1 Nickel frame with 3.2 mm diameter plain mounting holes.
- CP30622MBX1 Black metal frame with 3.2 mm diameter plain mounting holes.
-
RJ45 Cat.6 Shielded FTP SLIM narrow, metal, front-mounting, feedthrough connector. Gold-plated contacts.
- CP30622SM Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30622SMB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30622SMX1 Nickel frame with 3.2 mm diameter plain mounting holes.
- CP30622SMBX1 Black metal frame with 3.2 mm diameter plain mounting holes.
-
RJ45 Cat.6a Shielded FTP SLIM narrow, metal, front-mounting, feedthrough connector. Gold-plated contacts.
- CP30625SM Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30625SMB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30625SMX1 Nickel frame with 3.2 mm diameter plain mounting holes.
- CP30625SMBX1 Black metal frame with 3.2 mm diameter plain mounting holes.
USB 2
-
USB 2.0 A female to USB 2.0 A female SLIM narrow, metal, front-mounting, feedthrough connector. Gold-plated contacts.
- CP30608NM Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30608NMB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30608NMX1 Nickel frame with 3.2 mm diameter plain mounting holes.
- CP30608NMBX1 Black metal frame with 3.2 mm diameter plain mounting holes.
-
USB 2.0 A female to USB 2.0 B female SLIM narrow, metal, front-mounting, feedthrough connector. Gold-plated contacts.
- CP30609NM Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30609NMB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30609NMX1 Nickel frame with 3.2 mm diameter plain mounting holes.
- CP30609NMBX1 Black metal frame with 3.2 mm diameter plain mounting holes.
-
USB 2.0 B female to USB 2.0 A female SLIM narrow, metal, front-mounting, feedthrough connector. Gold-plated contacts.
- CP30607NM Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30607NMB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30607NMX1 Nickel frame with 3.2 mm diameter plain mounting holes.
- CP30607NMBX1 Black metal frame with 3.2 mm diameter plain mounting holes.
USB 3
-
USB 3.0 A female to USB 3.0 A female SLIM narrow, metal, front-mounting, feedthrough connector. Gold-plated contacts.
- CP30605NM Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30605NMB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30605NMX1 Nickel frame with 3.2 mm diameter plain mounting holes.
- CP30605NMBX1 Black metal frame with 3.2 mm diameter plain mounting holes.
-
USB 3.0 B female to USB 3.0 A female SLIM narrow, metal, front-mounting, feedthrough connector. Gold-plated contacts.
- CP30606NM Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30606NMB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30606NMX1 Nickel frame with 3.2 mm diameter plain mounting holes.
- CP30606NMBX1 Black metal frame with 3.2 mm diameter plain mounting holes.
USB Type C
-
USB Type-C female to USB Type-C male SLIM narrow, metal, front-mounting, feedthrough connector.
USB-C extension cables available.
- CP30611M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30611MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30611MX1 Nickel frame with 3.2 mm diameter plain mounting holes.
- CP30611MBX1 Black metal frame with 3.2 mm diameter plain mounting holes.
Blanking Plates
-
Blanking plate SLIM narrow, metal, front-mounting, feedthrough connector.
- CP30641M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30641MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30641MX1 Nickel frame with 3.2 mm diameter plain mounting holes.
- CP30641MBX1 Black metal frame with 3.2 mm diameter plain mounting holes.
Gaskets and Dust Covers
-
SLIM / DUALSLIM Gaskets and Dust Covers.
These rubber gaskets are used as dust seals and for colour color identification.
- CP299812 Black SLIM / DUALSLIM gasket.
- CP299815 Green SLIM / DUALSLIM gasket.
- CP299817 Red SLIM / DUALSLIM gasket.
- CP299818 Blue SLIM / DUALSLIM gasket.
- CP299822 Black DUALSLIM (countersunk) gasket with dust cover.
- CP299825 Green DUALSLIM (countersunk) gasket with dust cover.
- CP299827 Red DUALSLIM (countersunk) gasket with dust cover.
- CP299828 Blue DUALSLIM (countersunk) gasket with dust cover.
- CP299832 Black DUALSLIM (countersunk) dust cover.
- CP299835 Green DUALSLIM (countersunk) dust cover.
- CP299837 Red DUALSLIM (countersunk) dust cover.
- CP299838 Blue DUALSLIM (countersunk) dust cover.
Please contact Cliff™ sales for more information.
