DualSLIMs Narrow Metal Feedthrough Connectors - Front or Rear Mounting
The FT series of true, feed through, data connectors for electrical instrumentation are perfect for developing custom I/O configurations for wall plates, rack panels, etc.
The DualSLIMs are 19 × 35.5 mm, fit within a narrow 17.15 × 22.86 mm panel cutout and use common cabling for front and back connections. No soldering and no punch terminations - just use the standard cable for that particular connector style.
Mount from the front or the rear with various mounting hole options. Low rear profile.
Available in a variety of styles. Functionality is affected by cable quality, length and cable wiring configuration.
Jump down to BNC, DisplayPort, HDMI, RJ11, RJ12, RJ45, USB 2, USB 3, USB-C, Blanks, Dust Covers.
Please also see our feedthrough connectors, XLR audio and XLR format connectors and USB connectors.
BNC
-
BNC 50 ohm DualSLIM narrow, metal, front or rear mounting connector.
- CP30737M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30737MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30737M3 Nickel frame with M3 mounting holes.
- CP30737MB3 Black metal frame with M3 mounting holes.
- CP30737M440 Nickel frame with #4-40 UNC mounting holes.
- CP30737MB440 Black metal frame with #4-40 UNC mounting holes.
- CP30737MX1 Nickel frame with 3.2 mm plain mounting holes.
- CP30737MBX1 Black metal frame with 3.2 mm plain mounting holes.
-
BNC 75 ohm DualSLIM narrow, metal, front or rear mounting connector.
- CP30738M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30738MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30738M3 Nickel frame with M3 mounting holes.
- CP30738MB3 Black metal frame with M3 mounting holes.
- CP30738M440 Nickel frame with #4-40 UNC mounting holes.
- CP30738MB440 Black metal frame with #4-40 UNC mounting holes.
- CP30738MX1 Nickel frame with 3.2 mm plain mounting holes.
- CP30738MBX1 Black metal frame with 3.2 mm plain mounting holes.
DisplayPort
-
DisplayPort female to female DualSLIM narrow, metal, front or rear mounting, feedthrough connector. 8K @ 60Hz. Gold-plated contacts.
DisplayPort to DisplayPort cables are available in 1m and 2m lengths.
- CP30733M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30733MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30733M3 Nickel frame with M3 mounting holes.
- CP30733M3B Black metal frame with M3 mounting holes.
-
Mini DisplayPort female to female DualSLIM narrow, metal, front or rear mounting, feedthrough connector. Gold-plated contacts.
DisplayPort to mini DisplayPort cables are available in 1m and 2m lengths.
- CP30702M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30702MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30702M3 Nickel frame with M3 mounting holes.
- CP30702MB3 Black metal frame with M3 mounting holes.
- CP30702M440 Nickel frame with #4-40 UNC mounting holes.
- CP30702MB440 Black metal frame with #4-40 UNC mounting holes.
- CP30702MX1 Nickel frame with 3.2 mm plain mounting holes.
- CP30702MBX1 Black metal frame with 3.2 mm plain mounting holes.
HDMI
-
HDMI 4K female to HDMI 4K female DualSLIM type-A, narrow, metal, front or rear mounting, feedthrough connector. Gold-plated contacts and shell.
There is also a right-angled version.
- CP30700GM Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30700GMB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30700GM3 Nickel frame with M3 mounting holes.
- CP30700GMB3 Black metal frame with M3 mounting holes.
- CP30700GM440 Nickel frame with #4-40 UNC mounting holes.
- CP30700GMB440 Black metal frame with #4-40 UNC mounting holes.
- CP30700GMX1 Nickel frame with 3.2 mm plain mounting holes.
- CP30700GMBX1 Black metal frame with 3.2 mm plain mounting holes.
-
HDMI 8K female to HDMI 8K female DualSLIM type-A, narrow, metal, front or rear mounting, feedthrough connector. Gold-plated contacts and shell.
Shielded HDMI 2.1 supporting 7680 × 4320 at 60 Hz with HDR video support.
- CP30788M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30788MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30788M3 Nickel frame with M3 mounting holes.
- CP30788MB3 Black metal frame with M3 mounting holes.
- CP30788M440 Nickel frame with #4-40 UNC mounting holes.
- CP30788MB440 Black metal frame with #4-40 UNC mounting holes.
- CP30788MX1 Nickel frame with 3.2 mm plain mounting holes.
- CP30788MBX1 Black metal frame with 3.2 mm plain mounting holes.
RJ11 / RJ14
-
RJ11 / RJ14 (6P4C) Cat.3 DualSLIM narrow, metal, front or rear mounting, feedthrough connector. Gold-plated contacts.
- CP30723M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30723MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30723M3 Nickel frame with M3 mounting holes.
- CP30723MB3 Black metal frame with M3 mounting holes.
- CP30723M440 Nickel frame with #4-40 UNC mounting holes.
- CP30723MB440 Black metal frame with #4-40 UNC mounting holes.
- CP30723MX1 Nickel frame with 3.2 mm plain mounting holes.
- CP30723MBX1 Black metal frame with 3.2 mm plain mounting holes.
RJ12
-
RJ12 (6P6C) Cat.3 DualSLIM narrow, metal, front or rear mounting, feedthrough connector. Gold-plated contacts.
- CP30724M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30724MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30724M3 Nickel frame with M3 mounting holes.
- CP30724MB3 Black metal frame with M3 mounting holes.
- CP30724M440 Nickel frame with #4-40 UNC mounting holes.
- CP30724MB440 Black metal frame with #4-40 UNC mounting holes.
- CP30724MX1 Nickel frame with 3.2 mm plain mounting holes.
- CP30724MBX1 Black metal frame with 3.2 mm plain mounting holes.
RJ45
-
RJ45 Cat.5e Unshielded UTP DualSLIM narrow, metal, front or rear mounting, feedthrough connector. Gold-plated contacts.
There is also a right-angled version.
- CP30720M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30720MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30720M3 Nickel frame with M3 mounting holes.
- CP30720MB3 Black metal frame with M3 mounting holes.
- CP30720M440 Nickel frame with #4-40 UNC mounting holes.
- CP30720MB440 Black metal frame with #4-40 UNC mounting holes.
- CP30720MX1 Nickel frame with 3.2 mm plain mounting holes.
- CP30720MBX1 Black metal frame with 3.2 mm plain mounting holes.
-
RJ45 Cat.5e Shielded FTP DualSLIM narrow, metal, front or rear mounting, feedthrough connector. Gold-plated contacts.
- CP30720SM Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30720SMB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30720SM3 Nickel frame with M3 mounting holes.
- CP30720SMB3 Black metal frame with M3 mounting holes.
- CP30720SM440 Nickel frame with #4-40 UNC mounting holes.
- CP30720SMB440 Black metal frame with #4-40 UNC mounting holes.
- CP30720SMX1 Nickel frame with 3.2 mm plain mounting holes.
- CP30720SMBX1 Black metal frame with 3.2 mm plain mounting holes.
-
RJ45 Cat.6 Unshielded UTP DualSLIM narrow, metal, front or rear mounting, feedthrough connector. Gold-plated contacts.
There is also a right-angled version.
- CP30722M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30722MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30722M3 Nickel frame with M3 mounting holes.
- CP30722MB3 Black metal frame with M3 mounting holes.
- CP30722M440 Nickel frame with #4-40 UNC mounting holes.
- CP30722MB440 Black metal frame with #4-40 UNC mounting holes.
- CP30722MX1 Nickel frame with 3.2 mm plain mounting holes.
- CP30722MBX1 Black metal frame with 3.2 mm plain mounting holes.
-
RJ45 Cat.6 Shielded FTP DualSLIM narrow, metal, front or rear mounting, feedthrough connector. Gold-plated contacts.
- CP30722SM Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30722SMB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30722SM3 Nickel frame with M3 mounting holes.
- CP30722SMB3 Black metal frame with M3 mounting holes.
- CP30722SM440 Nickel frame with #4-40 UNC mounting holes.
- CP30722SMB440 Black metal frame with #4-40 UNC mounting holes.
- CP30722SMX1 Nickel frame with 3.2 mm plain mounting holes.
- CP30722SMBX1 Black metal frame with 3.2 mm plain mounting holes.
-
RJ45 (8P8C) Cat.6 to IDC DualSLIM narrow, metal, front or rear mounting, connector. RJ45 has gold-plated contacts. The rear connectors are IDCs rather than a feedthrough.
- CP30727M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30727MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30727M3 Nickel frame with M3 mounting holes.
- CP30727MB3 Black metal frame with M3 mounting holes.
- CP30727M440 Nickel frame with #4-40 UNC mounting holes.
- CP30727MB440 Black metal frame with #4-40 UNC mounting holes.
- CP30727MX1 Nickel frame with 3.2 mm plain mounting holes.
- CP30727MBX1 Black metal frame with 3.2 mm plain mounting holes.
-
RJ45 Cat.6a Shielded FTP DualSLIM narrow, metal, front or rear mounting, feedthrough connector. Gold-plated contacts.
- CP30725SM Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30725SMB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30725SM3 Nickel frame with M3 mounting holes.
- CP30725SMB3 Black metal frame with M3 mounting holes.
- CP30725SM440 Nickel frame with #4-40 UNC mounting holes.
- CP30725SMB440 Black metal frame with #4-40 UNC mounting holes.
- CP30725SMX1 Nickel frame with 3.2 mm plain mounting holes.
- CP30725SMBX1 Black metal frame with 3.2 mm plain mounting holes.
USB 2
-
USB 2.0 A female to USB 2.0 A female DualSLIM narrow, metal, front or rear mounting, feedthrough connector. Gold-plated contacts.
- CP30708NM Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30708NMB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30708NM3 Nickel frame with M3 mounting holes.
- CP30708NMB3 Black metal frame with M3 mounting holes.
- CP30708NM440 Nickel frame with #4-40 UNC mounting holes.
- CP30708NMB440 Black metal frame with #4-40 UNC mounting holes.
- CP30708NMX1 Nickel frame with 3.2 mm plain mounting holes.
- CP30708NMBX1 Black metal frame with 3.2 mm plain mounting holes.
-
USB 2.0 A female to USB 2.0 B female DualSLIM narrow, metal, front or rear mounting, feedthrough connector. Gold-plated contacts.
- CP30709NM Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30709NMB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30709NM3 Nickel frame with M3 mounting holes.
- CP30709NMB3 Black metal frame with M3 mounting holes.
- CP30709NM440 Nickel frame with #4-40 UNC mounting holes.
- CP30709NMB440 Black metal frame with #4-40 UNC mounting holes.
- CP30709NMX1 Nickel frame with 3.2 mm plain mounting holes.
- CP30709NMBX1 Black metal frame with 3.2 mm plain mounting holes.
-
USB 2.0 B female to USB 2.0 A female DualSLIM narrow, metal, front or rear mounting, feedthrough connector. Gold-plated contacts.
- CP30707NM Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30707NMB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30707NM3 Nickel frame with M3 mounting holes.
- CP30707NMB3 Black metal frame with M3 mounting holes.
- CP30707NM440 Nickel frame with #4-40 UNC mounting holes.
- CP30707NMB440 Black metal frame with #4-40 UNC mounting holes.
- CP30707NMX1 Nickel frame with 3.2 mm plain mounting holes.
- CP30707NMBX1 Black metal frame with 3.2 mm plain mounting holes.
USB 3
-
USB 3.0 A female to USB 3.0 A female DualSLIM narrow, metal, front or rear mounting, feedthrough connector. Gold-plated contacts.
- CP30705NM Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30705NMB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30705NM3 Nickel frame with M3 mounting holes.
- CP30705NMB3 Black metal frame with M3 mounting holes.
- CP30705NM440 Nickel frame with #4-40 UNC mounting holes.
- CP30705NMB440 Black metal frame with #4-40 UNC mounting holes.
- CP30705NMX1 Nickel frame with 3.2 mm plain mounting holes.
- CP30705NMBX1 Black metal frame with 3.2 mm plain mounting holes.
-
USB 3.0 B female to USB 3.0 A female DualSLIM narrow, metal, front or rear mounting, feedthrough connector. Gold-plated contacts.
- CP30706NM Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30706NMB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30706NM3 Nickel frame with M3 mounting holes.
- CP30706NMB3 Black metal frame with M3 mounting holes.
- CP30706NM440 Nickel frame with #4-40 UNC mounting holes.
- CP30706NMB440 Black metal frame with #4-40 UNC mounting holes.
- CP30706NMX1 Nickel frame with 3.2 mm plain mounting holes.
- CP30706NMBX1 Black metal frame with 3.2 mm plain mounting holes.
USB Type C
-
USB Type-C female to USB Type-C female DualSLIM narrow, metal, front or rear mounting, feedthrough connector.
Not compatible with power delivery (PD) charging.
USB-C extension cables available.
- CP30701M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30701MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30701M3 Nickel frame with M3 mounting holes.
- CP30701MB3 Black metal frame with M3 mounting holes.
- CP30701M440 Nickel frame with #4-40 UNC mounting holes.
- CP30701MB440 Black metal frame with #4-40 UNC mounting holes.
- CP30701MX1 Nickel frame with 3.2 mm plain mounting holes.
- CP30701MBX1 Black metal frame with 3.2 mm plain mounting holes.
-
USB Type-C female to USB Type-C male DualSLIM narrow, metal, front or rear mounting, feedthrough connector.
USB-C extension cables available.
- CP30711M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30711MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30711M3 Nickel frame with M3 mounting holes.
- CP30711MB3 Black metal frame with M3 mounting holes.
- CP30711M440 Nickel frame with #4-40 UNC mounting holes.
- CP30711MB440 Black metal frame with #4-40 UNC mounting holes.
- CP30711MX1 Nickel frame with 3.2 mm plain mounting holes.
- CP30711MBX1 Black metal frame with 3.2 mm plain mounting holes.
Blanking Plates
-
Blanking plate DualSLIM narrow, metal, front or rear mounting feedthrough connector.
- CP30741M Nickel frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30741MB Black metal frame with 3.2 mm countersunk mounting holes (90 ° × ⌀5.85 mm).
- CP30741M3 Nickel frame with M3 mounting holes.
- CP30741MB3 Black metal frame with M3 mounting holes.
- CP30741M440 Nickel frame with #4-40 UNC mounting holes.
- CP30741MB440 Black metal frame with #4-40 UNC mounting holes.
- CP30741MX1 Nickel frame with 3.2 mm plain mounting holes.
- CP30741MBX1 Black metal frame with 3.2 mm plain mounting holes.
Gaskets and Dust Covers
-
SLIM / DUALSLIM Gaskets and Dust Covers.
These rubber gaskets are used as dust seals and for colour color identification.
- CP299812 Black SLIM / DUALSLIM gasket.
- CP299815 Green SLIM / DUALSLIM gasket.
- CP299817 Red SLIM / DUALSLIM gasket.
- CP299818 Blue SLIM / DUALSLIM gasket.
- CP299822 Black DUALSLIM (countersunk) gasket with dust cover.
- CP299825 Green DUALSLIM (countersunk) gasket with dust cover.
- CP299827 Red DUALSLIM (countersunk) gasket with dust cover.
- CP299828 Blue DUALSLIM (countersunk) gasket with dust cover.
- CP299832 Black DUALSLIM (countersunk) dust cover.
- CP299835 Green DUALSLIM (countersunk) dust cover.
- CP299837 Red DUALSLIM (countersunk) dust cover.
- CP299838 Blue DUALSLIM (countersunk) dust cover.
Please contact Cliff™ sales for more information.
Our site uses PDF (portable document format) files to store information on our products. To view these files you should have a PDF reader installed. You can download Adobe Acrobat Reader for free.
